EDGESlim140

EDGE Series

Control & Performance with Light Guides

Description

Product Code: ESM140

1.4″ Low-Profile Linear LED Fixture

The EDGESlim140 surface-mounted fixture from XICO is an innovative ultra-slim and compact LED linear product providing best-in-class efficiency and beam control options. The EDGESlim140 is designed to be specification-grade with high lumen per foot, high CRI, and circadian options. EDGESlim140 is powered by a high performance LED light engine with fully customizable choices for lumen output, CCT, and CRI. Based upon unique micro-optical technology; a key feature of the EDGESlim is that it delivers a wide range of beam distributions while achieving high efficacy, energy-saving performance. EDGESlim products are available with a range of accessories and mounting options.

Fixture Dimensions: 1.40″ (W) x 0.75″ (H)

Features & Benefits

Edge-lit light guide technology with choice of optics
Fusion Optix® Inside with SmartBeam® technology
Patented EDGETek® light guide innovations
Additional MICROTek® and FLATLens® Optics
Symmetric & asymmetric lighting distributions
Best-in-class efficiency and color quality
0-10V, DALI, DMX and Triac dimming. Dim-to-Warm
Choice of factory selected, Lutron or Eldoled drivers
Controls include; Lutron, Cooper, Casambi
Choice of finishes and customization options

Certifications

UL/ETL Listed
Declare listed and Red List Free
RoHS Compliant
Designed & Built in Boston MA
BABAA Compliance (Read Statement)
BIOS Certified Partner
5-Year Factory Warranty

Files & Downloads

Revit Files

Tech Drawings

Sustainability

Declare Label

BABAA Compliance

SmartBeam® Choices

Direct

Technical Specifications

Dimensions

Mounting Style

Mounting Types

Mounting Brackets

Standard Lengths

Finish

Housing Material

Warranty

Sustainability

1.4″ x 0.5″

Surface

Surface and T-Bar

Sheet Metal

1ft, 2ft, 3ft, 4ft, 6ft, 8ft

Powder Coated & Anodized

Extruded, Recycled Aluminum

5-Year Warranty

Declare Listed and Red List Free

LED Performance

LED Choices

Optics Choices

CRI

CCT

Lighting Configurations

Voltage

Driver Options

Emergency Backup

Compatible Controls Options

Power Cord

Up to 1,000 Lm/Ft, 150 Lm/W Efficacy

Static, Tunable, White, & Dim-to-Warm

Flat, Dome, Light Guide & MCO

80/90/95+

2700K to 6500K

Direct

120-277 VAC and 347 VAC, 50/60 Hz

Remote

Emergency Circuit & Emergency Battery

Lutron, Casambi & Cooper

24″

Sustainability

XICO_IMG_Hand_with_EDGERazor_Pendant_500x500

Declare.

XICO uses the Living Product Challenge framework to rethink the way our products are made. Instead of trying to be “less bad,” we are creating products that have a positive impact.

Declare is an ingredients label for building products paired with an online database of healthy materials for building project specifications. It allows manufacturers of ecologically sound products to demonstrate market leadership in the growing movement toward product transparency and health in the built environment and provides them an expanded point of entry into the world’s most groundbreaking sustainable building projects.

EDGE Series Declare Listing
